Top Entry Ball Valve

design standards
Top-mounted ball valve design specifications and design standards: API 6A, API 6D, ANSI B16.34, BS 5351

Structure length:ANSI B16.10

Connection standard:ANSI B16.5

Main material: carbon steel, stainless steel, alloy steel

Pressure test: API 598

Pressure range: Class600-1500 Caliber: 2″-12″

Features
Integrated valve body design, top-mounted pivot fixed support, flange structure, integral pivot fixed ball rod design, double blockage and relief function, high strength integrated ball rod structure.

To ensure the accurate positioning of the ball, the pivot adopts an anti-blowout protection structure, 2 sets of O-rings, and a fireproof packing structure on the valve stem.

Effectively prevent leakage and corrosion, the low friction coefficient bearing allows the nickel corrugated spring to move the nylon sealed metal valve seat towards the ball.
