Pn25 Cast Iron Y-strainer

PN25 cast iron Y-STRAINER

The Y-type filter is installed on the pipeline and can remove solid particles in the fluid, so that the machinery and equipment (including compressors, pumps, etc.) and instruments can work and operate normally, reduce losses, stabilize the process, and ensure safe production. . When the fluid enters the filter cartridge equipped with a filter screen of a certain specification, its impurities are blocked, and the clean filtrate is discharged from the filter outlet. When cleaning is needed, just take out the detachable filter cartridge and reinstall it after processing. It is very convenient to use and maintain.
The Y-type filter produced by our company can be customized according to customer requirements. The filter has a compact structure, easy installation and cleaning, and a large filtering area.
According to the manufacturing process and performance of the Y-type filter, the filter can be divided into: cast Y-type filter, welded Y-type filter, forged Y-type filter, tie rod telescopic Y-type filter, reducing Y-type filter filter, all-plastic Y-type filter, jacketed insulation Y-type filter, etc.

SIZE:DN15-DN2000

Medium: liquid, gas
Temperature: -80℃--+500℃
Nominal pressure: less than 42.0Mpa
Linking method: flange, butt welding, thread
Shell material: CS/304/316L/lining, all plastic
Flange standards: HG, GB, JB, ANSI, JIS, DIN
Filter element material: 304, 316L, PP, PTFE, PVC
Sealing surface form: RF, FF, M, FM, G, T, RJ
Gasket: PTFE, metal winding, graphite, silicone rubber, EPDM, fluorine rubber
Filtration precision: 10 mesh---500 mesh
