Cast Steel Globe Valve
Cast steel globe valve
1.When fully closed,the handwheel rotates clockwise.
2.Able to be mounted on any position of the pipeline,the medium flows from down to up.
3.Stainless steel made stop valve is of good anti-corrosive property and enough strength and suitable for various pipelines with corrosive medium.
4.Alloy steel made stop valve features high-temperature resistance,suitable for high-temperature steam and oil goods pipelines.
| PN(MPa)Nominal pressure | 1.6 | 2.5 | 4.0 | 6.4 | 10.0 | 16.0 |
| Shell strength test | 2.4 | 3.8 | 6.0 | 9.6 | 15 | 24 |
| Back seal test | 1.8 | 2.8 | 4.4 | 7.0 | 11 | 18 |
| Seal test | 1.8 | 2.8 | 4.4 | 7.0 | 11 | 18 |
| Product classification | Suitable medium | (℃)Suitable temperature |
| Water,steam,oilgoods | ≤425℃ ≤450℃ |
|
| Nitric acid | ≤200℃ | |
| Acetic acid | ≤200℃ | |
| Water,steam,oilgoods | ≤550℃ |
