Electric Wafer Type Soft Seal Butterfly Valve
Electric wafer type soft seal butterfly valve
Electric wafer-type soft seal butterfly valve actuator
Technical parameters of electric actuator: power supply AC110, 220, 380V, DC24, nominal diameter DN50~1200mm, output torque 50N·M~2000N·M, nominal pressure PN0.6, 1.0, 1.6Mpa, function selection: switch type, Passive contact type, valve position signal feedback type, intelligent adjustment type. Applicable temperature ≤120℃, suitable media for water, gas, oil and weakly corrosive fluids, input signal: 4-20mA, 1-5V, 0-10V; output signal: 4-20mA, 1-5V, 0-10V. Easy to use: single-phase power supply, simple wiring; unique spherical protruding structure, making observation more convenient; no need for refueling, no inspection, waterproof and rust-proof, and can be installed at any angle. The protection device has double limit, overheating protection and overload protection. Full travel time: 5 seconds, 10 seconds, 15 seconds, 30 seconds, 45 seconds, 60 seconds. And with manual function. The built-in module uses advanced computer single chip and intelligent control software to directly receive the standard signal (4-20mA DC /1-5VDC) output from a computer or industrial instrument to achieve intelligent control and precise positioning of the valve opening.
3810 series or PSQ series can also be used. Large-diameter valves generally use 380VAC electric actuators.
|
DN
|
L
|
H
|
H1
|
A
|
B
|
0.6MPa
|
1.0MPa
|
1.6MPa
|
|||
|
DO
|
n-d
|
DO
|
n-d
|
DO
|
n-d
|
||||||
|
50
|
43
|
63
|
306
|
180
|
200
|
110
|
4-14
|
125
|
4-18
|
125
|
4-18
|
|
65
|
46
|
70
|
321
|
180
|
200
|
130
|
4-14
|
145
|
4-18
|
145
|
4-18
|
|
80
|
46
|
83
|
346
|
180
|
200
|
150
|
4-18
|
160
|
8-18
|
160
|
8-18
|
|
100
|
52
|
105
|
387
|
180
|
200
|
170
|
4-18
|
180
|
8-18
|
180
|
8-18
|
|
125
|
56
|
115
|
411
|
180
|
200
|
200
|
8-18
|
210
|
8-18
|
210
|
8-18
|
|
150
|
56
|
137
|
447
|
270
|
280
|
225
|
8-18
|
240
|
8-22
|
240
|
8-22
|
|
200
|
60
|
164
|
572
|
270
|
280
|
280
|
8-18
|
295
|
8-22
|
295
|
8-22
|
|
250
|
68
|
206
|
646
|
270
|
280
|
335
|
12-18
|
350
|
12-22
|
355
|
12-26
|
|
300
|
78
|
230
|
738
|
380
|
420
|
395
|
12-22
|
400
|
12-22
|
410
|
12-26
|
|
350
|
78
|
248
|
761
|
380
|
420
|
445
|
12-22
|
460
|
16-22
|
470
|
16-26
|
|
400
|
102
|
289
|
877
|
450
|
470
|
495
|
16-22
|
515
|
16-26
|
525
|
16-30
|
|
450
|
114
|
320
|
938
|
480
|
490
|
550
|
16-22
|
565
|
20-26
|
585
|
20-30
|
|
500
|
127
|
343
|
993
|
480
|
490
|
600
|
20-22
|
620
|
20-26
|
650
|
20-33
|
|
600
|
154
|
413
|
1131
|
480
|
490
|
705
|
20-26
|
725
|
20-30
|
770
|
20-36
|
|
700
|
165
|
478
|
1476
|
640
|
660
|
810
|
24-26
|
840
|
24-30
|
840
|
24-36
|
|
800
|
190
|
525
|
1533
|
640
|
660
|
920
|
24-30
|
950
|
24-33
|
950
|
24-39
|
|
900
|
203
|
585
|
1655
|
750
|
860
|
1020
|
24-30
|
1050
|
28-33
|
1050
|
38-39
|
|
1000
|
216
|
640
|
1765
|
850
|
900
|
1120
|
28-30
|
1160
|
28-36
|
1170
|
28-42
|
|
1200
|
254
|
755
|
1995
|
850
|
900
|
1340
|
32-33
|
1380
|
32-39
|
1390
|
32-48
|
